Eager Beaver Trailer 10HA-PT
| Stock: 10HA-PT | Manufacturer: Eager Beaver Trailer |
Detailed Specs
Additional Information
EASYLOADERS
25880 lbs.
5,880 lbs
8 ft. 6 in. Length: 19 ft. Height: 34 in
Mainrails: W12" x 16 lbs. wide flange I-Beam, one piece cold formed
6" x 3.7 lbs. per ft. I-Beam pierced through mainbeam
Nominal 1 3/4" Hardwood
8" high, full width of trailer Drawbar Storage Area
12 volt L.E.D., DOT approved
USA Star PLUS Sealed Modular Wiring Harness w/ 7-Way ATA Plug
One piece solid cast steel (adjustable) lunette eye & flange mount
Two 3/8" Blue-Krome plated high test, safety hook w/ latch
12,000 lbs. static / 10,000 lbs. lift (Heavy Duty drop leg screw type
Five per side - Patented "ROTO RINGS"® Swivel 360
Black,Yellow, Blue (standard) Imron Paint
Eight 235/80R16 (E) Steel Belted Radial
Four 8 Stud on 6 1/2" BC (2 pc hub & drum),
Eight 6.00 x 16 Disc Type Wheels,
3" wide rubber bushed Slipper Spring w/ equalizer, capacity 20,000 lbs. tandem (Adj. Alignment)
Two Heavy Duty Dexter, 10,000 lbs. each, Inner Bearing Size 2.625", Outer Bearing Size 2.250"
Description
T Easy Loader Series 10 Ton Tag – (2) 10K ABS Air Brake Axles
